Horizontal Autoclave

Construction of this Autoclave is Double Walled, but the body is horizontal mounted on Tubular stand with S.S. Boiler.

Get A Quote

Horizontal Autoclave Construction for Enhanced Insulation

Our Horizontal Autoclave features a robust Double Walled construction that provides superior insulation. The double-layered design ensures minimal heat loss and optimal temperature control during sterilization.

Horizontal Body for Convenient Loading and Unloading

The autoclave body is horizontally mounted, allowing for easy loading and unloading of materials. This user-friendly design simplifies the sterilization process and saves valuable time and effort.

 Sturdy Tubular Stand for Stability and Safety

A durable Tubular stand supports the autoclave, ensure stability and safety during operation. This sturdy stand minimizes the risk of accidents and provides a solid base for the autoclave to operate easily.

Horizontal Autoclave S.S. Boiler for Efficient Steam Generation

Equipped with a high-quality S.S. Boiler, our autoclave generates steam efficiently. The stainless steel construction ensures Robustness and enables the autoclave to withstand high pressures and temperatures.

The Double Walled Autoclave we offer is designed to deliver secure and easily sanitization method. Its double-walled construction enhances insulation, assure optimal temperature control. The autoclave’s horizontal body simplifies material loading and unloading, saving time and effort. A sturdy Tubular stand provides stability and safety during operation. The autoclave’s stainless steel (S.S.) Boiler effectively produces steam for cleaning., guarantee effective results.

With our Horizontal Autoclave, you can trust in its construction and features to meet your purification needs. Experience the convenience of a horizontal body and easy loading and unloading.. Benefit from the stability and safety ensured by the sturdy Tubular stand. Count on the S.S. Boiler for efficient steam generation. Choose our autoclave for secure and Effective sterilization methods.

SPECIFICATION

Model

ALS-HAV-500E

ALS-HAV-750E

ALS-HAV-900E

ALS-HAV-1500E

ALS-HAV-2000E

Operating Temperature range Sterilizing 105-121 °C (Optional 105 to135 °C)
Heating 45-104 °C
Warming 45-95°C
Maximum Operating Pressure 15 PSI Gauge (Optional 30 PSI Gauge)
Temperature Display Digital
Pressure Display Analogue
Display range 30 PSI Gauge (Optional 60 PSI Gauge)
Heat Source 2.25KW 3 KW 3.5 KW 4 KW 5 KW
Safety Devices *Water Level Sensor *LID Interlock *Over temperature protection *Over Pressure Protection *Pressure Safety Valve
Time Display DigitalHorizontal Autoclave
Display Range 0 to 999 Mins
Chamber Dimension Dia (mm) x Depth(mm) 350 x 500 400 x 600 450 x 600 500 x 770 600 x 700
Chamber Capacity Ltrs 50 75 90 150 200
Chamber Material SS304
Dimension W x D x H 20 x 20 x 26 24 x 24 x 30 26 x 26 x 34 28 x 28 x 36 32 x 32 x 40
Weight Kgs 60 100 120 140 160
Rated Voltage Vac 220 220 220 220 220
Environmental Conditions Ambient temperature 10 to 45 deg Cel
Ambient Pressure :- Atmospheric
Relative Humidity:- 30 to 85 %
Accessories Stainless Steel Basket (Wire Mesh / Solid)
